The Servo Rigid (Rigid Coupling) SRG Model is a super-high-rigidity coupling developed specifically for servo motor applications. Unlike flexible couplings, it has no elements to absorb the misalignment of two shafts, providing extremely high torsional rigidity. This makes it ideal for applications requiring highly accurate power transmission, such as machine tools. Additionally, the outer diameter relative to torque can be smaller compared to flexible couplings, allowing for downsizing of the coupling and contributing to the reduction of the moment of inertia.

Features
- Super High Rigidity: Extremely high torsional rigidity as it does not absorb misalignment of the two shafts.
- Downsizing: Smaller outer diameter relative to torque, enabling the overall downsizing of the coupling.
- High Precision Power Transmission: Ideal for applications requiring high precision power transmission, such as machine tools.
- Reduction of Moment of Inertia: Downsizing the coupling helps reduce the moment of inertia.

Specifications
- Model Name: SRG Series
- Allowable Torque: Varies by model
- Maximum Rotation Speed: Varies by model
- Materials:
Main Body Material: High-quality alloy steel
Surface Treatment: Special treatment for high durability
- Operating Temperature Range: -10℃ to 80℃

Applications
- Machine Tools
- Servo Motor Related Equipment

The Servo Rigid (Rigid Coupling) SRG Model achieves high precision power transmission and downsizing in machine tools, also contributing to the reduction of the moment of inertia.

For more details, please download the PDF or feel free to contact us.
