Wire-to-Board Connector “3001 Series” by CKM Electronics

The 3001 Series by CKM Electronics is a high-reliability wire-to-board connector with 3.0mm pitch, supporting up to 12.5A and 250V. UL and RoHS compliant, ideal for industrial use.

■ Key Features
- Supports up to 12.5A current and 250V voltage
- 3.0mm pitch ideal for moderate-density layouts
- Compatible with 30–16 AWG wire sizes
- Offers 2 to 24 circuits for flexible configurations
- Made with UL94V-0 flame-retardant plastic, halogen-free
- Operating temperature range: −40°C to +105°C
- High conductivity copper contacts with tin or gold plating

■ Specifications
- Pitch: 3.0mm (0.118”)
- Max Current Rating: 12.5A (AWG #16)
- Max Voltage Rating: 250V
- Applicable Wire Size: 30–16 AWG
- Number of Circuits: 2–24
- Operating Temperature: −40°C to +105°C
- Insulator: High-temp thermoplastic UL94V-0
- Contact Material: Copper alloy, nickel base with matte tin/gold plating

■ Applications
- Power and signal connections for industrial equipment
- Internal wiring of automotive electronic modules
- Renewable energy systems (e.g., solar inverter terminals)
- Power systems in home appliances and HVAC units
- Medical and analytical device module interfaces

■ Industries Served
- Industrial automation and control equipment
- Automotive electronics and module manufacturers
- Renewable energy device manufacturers
- Medical equipment and testing instrument producers

The 3001 Series offers a durable, high-current solution designed for reliable performance in demanding industrial applications.

■ Please download the product PDF or contact us for further information.
