TOHO MEKKI (THAILAND) CO., LTD.
Most recent update: 2024-04-22
PR message
Available types: zinc plating, zinc-tin alloy plating, hard chrome plating, electroless nickel plating, painting (Teflon coating), polishing (barrel, shock spray). blast)
Bath type: Heafu bath
Appearance color: silvery white
Hardness: 800-1000Hv
Melting point: about 1900 degrees
Features: mirror gloss and excellent corrosion resistance.
high hardness and excellent wear resistance.
Bath type: neutral bath
Sn co-deposition rate: 60-90%
Appearance color Trivalent chemical treatment: colored
Corrosion resistance (white rust/red rust): SST: -/800 hours * Film thickness: 6 m
Hardness: 15-20Hv
Melting point: about 190 degrees
Features: high corrosion resistance and excellent secondary workability.
Good solderability and compatibility with bolts, etc.
Bath type: medium phosphorus (Pb-free)
P content: 7-9%
Appearance color: silvery white. *May turn blue during heat treatment.
Hardness: 500–600 HV (up to 1000 HV during heat treatment)
Melting point: about 890 degrees
Features: Excellent dimensional accuracy and plating on the inner surface of the product.
compatible with not only iron but also brass and aluminum materials
Scratch hardness (pencil method): 2H or more*
Dynamic or static friction coefficient: 0.08 or 0.12 *
Appearance color: grayish black *
Operating temperature range: -60 to 300°C *
feature
It has characteristics such as corrosion resistance, wear resistance, low friction, permanent lubrication, non-adhesion, and water repellency, and is good at processing sliding parts.
Various metal materials can be handled by performing surface treatments.
Bath type: zincate bath
Appearance color trivalent conversion treatment: colored, black
Corrosion resistance (white rust/red rust): SST: 72/240 hours * film thickness: 8 m
Hardness: 120-140Hv
Melting point: about 420 degrees
Features: Good throwing power; can be used for both barrel and stationary
Appearance color is blue to yellow (reddish interference color), black.
 |
Zinc (rack)（ Surface treatment / Plating/Chemical conversion treatment ） |
|---|
| Company name | TOHO MEKKI (THAILAND) CO., LTD. | Website URL | |
|---|---|---|---|
| Street address |
Nongkhaka, Phanthong Chonburi Kingdom of Thailand
[See map] |
Person in charge | GO TAKAYA |
| Telephone number | +66-38-212344 | Fax number | +66-38-212347 |
| Capital | Employees | 60 | |
| Annual sales | Unregister | EMIDAS Member Number | 92588 |
| Main 3 products |
|
||
| Large | Medium | Small |
|---|---|---|
| Surface treatment | Plating/Chemical conversion treatment | Zinc (barrel) Chromate (general) Zinc (rack) Electroless nickel (barrel) Electroless nickel (rack) Chemical conversion coating Baking (hydrogen embrittling) Iron Copper Brass Aluminum Other anti-rust treatments Hard chromium (rack) Black oxide finish Unichromate (white) Black chromate (black/green) Colored chromate (multi-color) |
| Surface treatment | Barrel polishing | Barrel finishing (rotation) |
| Surface treatment | Other surface treatment | Teflon coating |
